卧式退火炉辐射冷却系统缓冷段装置及控制方法

发明人：卢纪平，余伟，郭万青，章培莉

摘要：一种退火炉辐射冷却系统缓冷段装置及其控制方法,所述缓冷段装置设置为48个区段,每个区段分别设置一个空气流量控制阀(3)及温度检测仪,当温度检测仪检测到炉内温度时,信息通过反馈控制器(11)来调节空气流量调节阀;每个区段均在带钢的上下方交叉布置辐射套管(2),通过辐射套管中的冷空气辐射来对带钢进行降温冷却,连接各区段的流量调节阀(3)经空气管道(4)连接至抽风机(5)后由排气烟囱(6)排出.

 One kind of radiation annealing furnace slow cooling zone cooling system device and control method, the device is set to slow cooling section 4--8 zones, each zone are provided an air flow control valve (3) and temperature detector when the temperature detector detects the temperature in the furnace, information feedback controller (11) to regulate the air flow control valve; beneath each cross section are arranged in the strip of radiation sleeve (2), set by radiation (6) is discharged from the exhaust chimney in cold air to cool the radiation cooling of the strip, each segment connecting the flow control valve (3) through the air duct
